General

• Storage Capacity: 240 GB

• Form Factor: 2.5-inch (6.35 cm)

• Interface: SATA III (6 Gb/s)

• NAND Technology: 3D NAND Flash

• Series: BX500

Performance

• Sequential Read Speed: Up to 540 MB/s

• Sequential Write Speed: Up to 500 MB/s

• Random 4K Read: ~95K IOPS

• Random 4K Write: ~90K IOPS

• Latency: Low-latency performance for faster system response

Reliability & Endurance

• MTTF (Mean Time to Failure): 1.5 Million Hours

• Endurance (TBW): ~80 TBW (TeraBytes Written)

• Error Correction: Integrated ECC (Error Correction Code)

• Operating Temperature: 0°C to 70°C

Compatibility

• Supported Devices: Laptops, Desktops, Compatible with any 2.5-inch SATA bay

• Backward Compatibility: Supports SATA II and SATA I

Physical

• Dimensions: 100.45 mm x 69.85 mm x 7 mm

• Weight: Approx. 40 g

Power

• Power Consumption (Active): 2.2W (typical)

• Power Consumption (Idle): 80mW

• Low Power Modes: Supported (Device Sleep mode)

Additional Features

• Shock Resistance: 1500G/0.5ms

• Vibration Resistance (Operating): 5 gRMS, 10–2000 Hz

• Vibration Resistance (Non-Operating): 10 gRMS, 10–2000 Hz

• Firmware Upgradeable: Yes

• Software Support: Crucial Storage Executive Tool (for drive monitoring & updates)

Warranty

• Warranty: 3 Years Limited Warranty (may vary by region)
